Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping

Basic Information
Place of Origin: China
Brand Name: Yushun
Certification: ISO 9001
Model Number: Customized
Minimum Order Quantity: 1
Price: Negotiated
Packaging Details: Wooden case packing or nude packing
Delivery Time: 30 days
Payment Terms: T/T, L/C
Supply Ability: 1 set 30 days
Detail Information
Name: ISO 9001 Auto Steel Bar Metal Bundle Strapping Machine Bundling Equipment Condition: New
Type: Strapping Equipment Specification: According To The Actual Condition
Application: Steel Rolling Line Size: Customized
Voltage: Depending On Production After Sales Service: Online Support, Field Installation
High Light:

iso 9001 steel bar machine

,

auto bundle strapping steel bar machine

,

ac380v bar bundling machine


Product Description

ISO 9001 Auto Steel Bar Metal Bundle Strapping Machine Bundling Equipment
Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 0

Technical Features:

1. Lift cover type panel, easy maintenance.
2. New electric heating device, fast heating, long service life.
3. Single chip electronic control, complete functions, easy operation.
4.

Four bundling methods to ensure a wide range of customer bundling requirements.

5. Low cost of packing string.



1. The wire guide groove was improved, the interface guide Angle was increased, and the integral processing method of the guide groove ensured the quality of the guide groove.The guide wheel on the guide groove adopts the structure form of hanging installation, so that the oxide sheet of the rod can automatically flow out;Therefore, effectively solve the problem of wire rod jamming, ensure that the wire rod delivery is smooth.

2. Whether the wire rod is in place, the indirect detection method is widely used at home and abroad, sometimes because the quality of the wire rod is not good or slip and other reasons, affecting the reliability of the test.The company adopts the special wire rod in place direct detection patent technology, directly detect the wire rod, the detection is accurate and reliable, effectively solve the resulting bundling fault, automatic bundling work for stability.

3. Good structural design and manufacturing process guarantee, optimize the use of detection and control technology, so that Huju automatic baler baling for the smooth, its speed, efficiency.

4. The hydraulic system pipeline adopts the card sleeve type installation, the hydraulic cylinder seal adopts the import seal, ensures the hydraulic system is reliable, achieves the hydraulic system has no leakage.

5. The installation of our automatic baling machine is simple, user only needs to provide 380V three-phase.



Performance index:

1. Bundling diameter range Φ100~Φ400
2. Bundle bale weight 1500KG-4000KG
3. Bundle bale shape round
4. Suitable steel specification deformed steel bar, (Φ10~140)round bar
5. Bundling object temperature ≤300℃
6. Bundling wire material and specification

Q195,specification is Φ5.5~7(recommend Φ6.5)green rod



7. Bundling type single wrap, single knot
8. Knot angle 630°
9. Single track bundling time 7~12 seconds
10. Working temperature -10℃-40℃
11. Control mode

manual and automatic with the function of interlocking communication with the production line



12. Installation weight ~4tons
13. Power supply three-phase four-wire AC380V+PE 50HZ
14. Installed gross capacity 16KW
15. Contour size of the unit 3600x1250x2050



Condition: New
Type: Packing machine
Warranty of core components: 1 Year
Core components: Bearing, Gearbox, Motor, Gear
Voltage: According to the actual condition
Power: Negotiated
Dimension(L*W*H) Customized
Output: Negotiated
After-sales-Service Provided: Field installation, commissioning and training, Field maintenance and repair service
Applicable industries: Manufacturing plant, construction works
Application: Steel Industry
Color: Customized
Billet size: Customized





Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 1Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 2

Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 3Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 4Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 5


Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 6
Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 7
Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 8
Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 9
Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 10
Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 11
Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 12




Iso 9001 AC380V Steel Bar Machine Auto Metal Bundle Strapping 13
Packaging Details: Wooden case packing or nude packing
Port: Tianjin
Lead Time:

Quantity(Sets) 1-1 >1
Est.Time(Days) 30 To be negotiated
